Performance at a glance — GTX60G / GTX71G
±0.04%
Reference accuracy (GTX60G)
200:1
Turndown ratio
10 yr
Long-term stability ±0.1% URL
GTX60G measuring span
17.5 – 3,500 kPa
2.54 – 508 psi
GTX71G measuring span
0.7 – 14 MPa
101 – 2,030 psi
Max working pressure
6,000 psi
GTX71G overload: 21 MPa
Response time
< 100 ms
Damping 0–128 sec adjustable
Power supply
12.5 – 42 V DC
IS/NI types: 12.5–30 V DC
Output signal
4 – 20 mA DC
NAMUR NE43: 3.8–20.5 mA
Communication protocols
4–20 mA (SFN)A
HART 5B
FOUNDATION FieldbusC
Digital DED
Bilingual DE/HART5E
HART 7F
Physical & installation
Center body316 SST
Transmitter caseAluminum alloy / CF8M
WeightApprox. 1.3 kg
ProtectionNEMA 4X, IP66/67
Pipe mounting2" horizontal or vertical
Conduit entryG1/2, ½ NPT, M20
Process connection½ NPT, R½, G½, Rc½
Operating limits
Ambient temp (GTX60G)-40 to +85 °C
Ambient temp (GTX71G)-25 to +70 °C
With digital indicator-25 to +80 °C
Humidity5 – 100 %RH
Vibration (high, GTX60G)3G (10–2000 Hz)
Lightning protectionIEC 61000-4-5, 6000 A
Grounding100 Ω max.
Certifications
SIL-2 / IEC 61508
FM Explosionproof (F1)
FM Intrinsic Safety (F2)
FM Nonincendive (F5)
ATEX Flameproof (A1)
ATEX Intrinsic Safety (A2)
IECEx Flameproof (E1)
IECEx Intrinsic Safety (E2)
NEPSI Flameproof (N1)
KCs Flameproof (K1)
⚠️ Load resistance: 250–1,345 Ω for SFN/DE communication; 250–600 Ω for HART. A minimum of 250 Ω is required for communicator use. Intrinsic safety types limited to 12.5–30 V DC supply.
💡 Why the GTX stands out: The 200:1 turndown ratio means a single model covers applications from near-vacuum to high pressure — reducing the number of spare parts you need to stock. The ±0.1% URL / 10-year stability rating eliminates routine calibration downtime, which Azbil claims is the best in the industry for this class of transmitter.
